Compression Testing Machine Digital Economy 1000 KN



Specification

The loading unit consists of a cross-head and base with solid channel supports connecting the base and cross-head firmly.
Resolution 0.1 KN. Manual Pace rate control and Manual release of pressure.
Reading in KN with peak hold and reset facility. Manual Calculation of strength.
Manual Pace rate Control will have certain limitations.
CTM with Automatic Pace rate control is recommended for accurate Pace rate Setting.

The digital compression testing machine has been designed to meet the need for a simple and economic means to test concrete for its compressive strength.
Loading Unit
The loading unit consists of a cross-head and base with solid channel supports connecting the base and cross-head firmly.

The Hydraulic jack is fixed to the base.
The platen of the machine are hardened ground and polished.
The upper platen is provided with self-aligning action.
To facilitate testing of various size specimens. Platen is adjustable with adjusting screw.
The machine is equipped with Manual pace rate controller.
The pace rate of the machine is manually controllable with slow / fast Oil pressure valve.

The Complete unit comprises a Loading Unit which is of Solid channel welded construction, having a cross-head with a spherical seated platen.
The lower platen is attached to the top of the piston. The Loading capacity is of 1000 KN, Cubes up to 150 mm can be tested.

The pump facilitates rapid approach of the platens for daylight closure and also provides  Manual control over the application of load.
Maximum load is held and retained for approx. 15 min, unless cancelled, using the panel mounted reset switch.

Type of Pumping    Electrical
Loading Range: 1000 KN
Least count: 0.1 KN or better
Ram dia: 165 mm
Ram Travel in mm: 50 mm
Platen dia: 200 mm
Horizontal clearance: 250 mm
Vertical daylight in mm: 300 mm
Overload Protection: Yes
Sort circuit protection: Yes
Pump Speed: Dual speed
Motor: Induction Motor
Reading: Digital
Accuracy: ± 2%
Release valve operation: Required
Auto stop after failure of specimen: Available, Machine stops after completion of test
Auto Release of Pressure after specimen failure: Not Available, Need to release pressure manually after the completion of test
Holding of Max.Load: Available
Pace Rate or Rate of Loading indication: Not Available
Operator skill to control Pace Rate: Not Applicable
Bar Graph: Not Available
Multi Channel operation    Not Available
Load indication and Control: Digital membrane key pad controller
Saving of records: Not Available
Pen drive slot: Optional
Real time graph: Not Applicable
Printer interface (Direct connectivity: Not Applicable
to printer w/o computer)
Computer operation software and: Not Applicable
data Acquisition software
Displacement controlled operation: Not Available
Modulus of Elasticity Calculation: Not Available
Flexural attachment: Possible, all calculations will be made manually
Splitting Tensile Test: Possible but manual calculation required
LAN Connectivity: Not Available
Auto internal Calibration without: Not Available
proving ring
Piston over travel safety cut off: Not Available
Over load safety cut off: Available
