Impact of a Jet Apparatus

Impact of a Jet Apparatus

The Impact of a Jet Apparatus module consists of a cylindrical tank with lateral transparent surfaces where a nozzle, connected to the Hydraulics Bench is aligned with a device in which the problem surface is fitted.
The vertical force made by the water against the surface is measured using calibrated weights that balance this force.
Taking as a reference a gauge, which has been previously adjusted to a zero reference, we measure the force thanks to a mark that appears on the surface where the masses were placed.
The dead weight of the moving parts is counterbalanced by a compression spring.
The vertical force exerted on the target plate is measured by adding the weights supplied to the weight pan until the mark on the weight pan corresponds with the level gauge.
Holes made on the tank base in order to drain the water.
In this way, splashes are avoided.

Discharge nozzle inside clear acrylic cylinder
Impact against a flat surface.
Measuring the force exerted on different targets and comparison with the forces predicted by momentum theory
Impact against a curve surface of 120o.
Impact against a hemispherical surface.
Measurement of the jet forces via the weight-loaded scale
Apparatus could be accommodated on the top surface of fluid mechanics bench
Flow rate could be measured via the flow meter of the fluid mechanics bench.
Use of the fast connectors.

Jet diameter: 8 mm.
Impact surfaces diameter: 40 mm.
A set of masses of 5, 10, 50 and 100 g. is supplied.
Easy and quick coupling system built-in.

Impact surfaces:
180° hemispherical surface.
120° curve surface.
90° flat surface.
